Load your component in TruTops Weld and mark the seams to be welded. The software is easy to use. Select your values. The program is created automatically. In fact, offline on the computer. Overall, you can program quicker and reduce non-productive times significantly.
Automated laser welding with TRUMPF – full flexibility, top productivity
As a global technology leader for machine tools and lasers for industrial production, we view it as our duty to design production technology to be efficient, precise, future proof and networked. We have developed a turnkey system for laser welding that has been supplemented with numerous intelligent functions. With the aid of various component positioners and numerous options, our TruLaser Weld 5000 can be precisely adapted to your requirements.
TeachLine – reliably detects the position of the weld seam.
TeachLine reliably detects the position of the component and adjusts your program correspondingly before welding.
What the experts say
"The demand for laser welding work increased so quickly that just one year later, we purchased a second laser welding cell."
TruTops Weld – program faster and produce at the same time
Create your welding program quickly and easily on the computer using the TruTops Weld offline programming system, thereby reducing non-productive time on your TruLaser Weld 5000.
From the CAD model to the welding program: infour simple steps
What the experts say
"With laser tacking, deep penetration welding and heat conduction welding, we have a processing spectrum that allows us to weld a very large variety of components. We will capitalise on this flexibility."
"For years, our focus was on avoiding welding connections. Now the tide has turned. A simpler design is made up of multiple single parts, but the welding connections are so perfect that we do not have to regrind."
Our turnkey, all-round carefree package
The shielding gas nozzle rotates continuously around the optics. The robot does not need to reorient itself for this. This also reduces your outlay on clamping systems and programming. Conclusion: with the rotation module, accessibility to your components is improved and you can weld significantly faster.
Work in a way that is more user friendly
Numerous functions, such as the swivelling operating panel, make your TruLaser Weld 5000 particularly user friendly. An additional status monitor on the machine shows the status of the current order from a distance. You can program your components easily using TruTops Weld in the office or directly at the robot. You can quickly select existing programs via the production screen on the operating panel. Large windows give you a good view into the work area – the automatically opening door allows quick access. The swivelling operating panel and the additional status monitor make your TruLaser Weld 5000 particularly user friendly.
Designing clamping fixtures can be a challenge for novices in laser welding. The modular clamping system comes to the rescue: with just one fixture, you can clamp components of different sizes and shapes and weld butt joints or 90° angles. The device can be adjusted to your workpiece in an instant.
Flexible laser welding
With various welding processes in one system – on your TruLaser Weld 5000 laser welding cell, various welding processes are available to you: heat conduction welding, deep penetration welding or FusionLine. Tap into the potential in order to reduce your component costs significantly. You can adjust the process easily using the welding program; you can also adjust the shielding gas amount and the strength of the compressed air crossjet at the optics. You receive a library of welding parameters with the machine.
The right machine for laser welding in a modern sheet metal processing system Robots, lasers, processing optics, safety cabin and positioning units: the turnkey system can be individually adjusted to your needs for automated welding with the laser.
