With the cordless TruTool F 300, you can close Pittsburgh lock seams on straight and curved ducts. You can work quickly with the quiet roll/glide process and achieve a tight connection. The sheet thickness range for this is 0.03 inches to 0.05 inches for mild steel. The adjustment to the sheet thickness is automatic. For example, with the 4 Ah rechargeable battery you can cut up to 57 meters in mild steel and a sheet thickness of 1 mm.
Suitable for flange heights of 9 mm – 13 mm and for sheet thicknesses of 0.75 – 1.25 mm.
Automatic adjustment to the sheet thickness always gives you consistent seam results.
With the TruTool F 300, you can close seams on straight and curved ducts.
The rechargeable battery achieves a runtime that is up to 60% longer due to the Power Head Technology and brushless motor.
For closing Pittsburgh seams
On straight or curved ducts with flange heights of 9 mm – 13 mm and sheet thicknesses of 0.75 mm – 1.25 mm for mild steel
The following consumables and the corresponding accessories are included in the scope of delivery.
1 unti 0067849
1 unti 0118860
1 unti 0138648
1 unti 2272665
1 unti 2272758
1 unit 1770951
Find the right consumables and accessories for your machine here.
Up to 60% more rechargeable battery running performance
The Power Head Technology is specifically designed for low-voltage rechargeable battery technology and ensures up to 20% longer running performance per battery charge. With its high torques, low power consumption, and minimal heat generation, the brushless motor provides even greater battery performance. This means that you can work for up to 40% longer. The 4 Ah rechargeable battery reaches up to approx. 57 meters in mild steel and a sheet thickness of 1 mm and, in the case of a sheet thickness of 1.25 mm, you can reach up to approx. 41 meters.
Compact, lightweight, and compatible
The 18 V battery machine has a compact and light design and allows fatigue-free work. The soft grip ensures safe and low-vibration working. You can combine the 18 V Li-ion rechargeable batteries with all current TRUMPF battery machines and the recharger in their voltage class. The Li-ion battery machines are also available as solo machines.
Optimal working speed
You can use the speed controller to adjust the working speed to suit the individual cutting task. It is extremely efficient if you work in accordance with the predefined cutting lines or a template. It is also well-suited to frequent processing of radii and stainless steel. The electronic overload protection offers yet another notable benefit.
TruTool F 300 Li-ion rechargeable battery 18 V
|Maximum sheet thicknesses|
|Maximum sheet thickness, steel up to 400 N/mm² (min.)||0.75 mm|
|Maximum sheet thickness, steel up to 400 N/mm² (max.)||1.25 mm|
|Flange height (B)|
|Flange height (B) with sheet thickness 0.75 - 1.0||9-11 mm|
|Flange height (B) with sheet thickness > 1.0 - 1.25||11-13 mm|
|Smallest inside radius (preformed)||150 mm|
|Smallest outside radius||300 mm|
|Max. lock seam thickness||0.75 mm|
|Working Speed||4 m/min - 7 m/min|
|Weight (with 2 Ah rechargable battery)||5.8 kg|
|Weight (with 4 Ah rechargable battery)||6 kg|
The technical data of all product versions as a download.
This product range and information may vary depending on the country. Subject to changes to technology, equipment, price, and range of accessories. Please get in touch with your local contact person to find out whether the product is available in your country.
