Beveler

TruTool TKF 1500 with 2-speed gearbox

The powerful tool with 2 gears

The TruTool TKF 1500 is equipped with a powerful 2600 W motor and a 2-speed gearbox. This enables you to carry out individual processing adapted to the respective application. Integrated hand protection on the motor ensures a high degree of user-friendliness and provides you with safety during operation. The soft grip enables you to work with low vibrations. This means you can always expect consistent, oxide-free results. Regardless of whether you are processing straight sheets, T-beams or tubes. The surface roughness remains low.

2-speed gearbox

Guarantees perfect results to match the material thickness, strength and type of workpiece.

2600 W motor

The extremely powerful motor ensures a high degree of durability.

Safe operation

Integrated hand protection on the motor provides you with a high degree of safety when working.

The right setting

It is quick and easy to adjust the optimal settings for the chamfer height and sheet thickness.

Continuously adjustable from 20° to 55°

You can use the carrier for various angles between 20° and 55°.

Bevellers: video on the area of application
TruTool TKF 1500 with 2-speed gearbox, dimensional drawing

The right choice

There are five cutting tools to choose from. This enables you to achieve perfect results across a wide range of applications. The material being processed is the determining factor when it comes to choosing the right cutting tool. The cutting tools can be interchanged without the need for additional tools, and you can regrind these many times over. This results in a long service life and reduces your operating costs.

Adapted speed

The TruTool TKF 1500 is equipped with a 2-speed gearbox, thus enabling the individual processing of various materials. A reduced stroke rate is recommended for work on high-tensile materials. This ensures a high-quality welding edge.

For straight edges and radius edges

Welding seam preparation on outer and inner contours. With interior cutout diameters from 130 mm. Also for T-beams and double T-beams.

Tubes

Welding seam preparation on tubes with an inside diameter from 30 mm.

The following consumables and the corresponding accessories are included in the scope of delivery.

Punching and nibbling oil for steel, 500 ml bottle
1 unit 0103387
High-tensile cutting tool (integrated)
Integrated
Hexagon-head screw M 10 x 20 - 10.9 DIN 933
1 unit 0017302
Chip box
1 unit 0023209
Allen key 6 mm
1 unit 0118860
Hexagon-head screw (2 units) M 10 x 25 - 10.9 DIN 933
1 unit 0079310
Tube of grease "S1", 25 g
1 unit 0121486
Tube of grease "S1", 250 g
1 unit 0385478
Wrench AL17 DIN 3113
1 unit 0078310
Grease gun
1 unit 0068624
Tube-shaped handle
1 unit 0023206
Handle base
1 unit 0023229
Setting gauge
1 unit 1411767
Roller holder complete, right
1 unit 1238982
Case
1 unit case 2277078

Find the right consumables and accessories for your machine here.

Work station with pedestal

Ideal for processing small parts in stationary use. For TruTool TKF 2000, order the adapter 1653155 separately.

1 unit  0005079
High-tensile cutting tool 5575

For processing mild steel between 600 and 800 N/mm2

Set of 2  1327480
Set of 10  1327482
Tube processing roller holder

For tube external machining Ø 90 - 200 mm with stripper

1 unit  0005123
Aluminium cutting tool

For processing aluminium between 200 and 400 N/mm2

Set of 2  1264419
High-tensile cutting tool

For processing mild steel between 500 and 700 N/mm2

Set of 10  1264418
Set of 2  1264417
Stripper

For an angle of bevel between 20° and 45°. For special part no. 0027798 for tube processing.

1 unit  0023242
Left roller holder

1 unit  1240848
Sliding sleeve

1 unit  1884873
Punching and nibbling oil for steel

500 ml  0103387
Modification kit 120 - 160 mm

Modification kit for greater workpiece thicknesses of 120 - 160 mm

1 unit  0027799
Heavy-duty cutting tool

For processing mild steel between 700 and 900 N/mm2

Set of 2  1264420
Set of 10  1264432
Modification kit 80 - 120 mm

Modification kit for larger workpiece thicknesses 80 - 120 mm

1 unit  0023204
Modification kit 40 - 80 mm

Modification kit for greater workpiece thicknesses of 40 - 80 mm

1 unit  0023203
Handle

Enables fatigue-free work with maximum movement

1 unit  0023210
Work station TKF1500/2000

Ideal for processing small parts in stationary use. For TruTool TKF 2000, the adapter 1653155 must be ordered separately.

1 unit  1343474
Punching and nibbling oil for aluminium

1000 ml  0125874
Case

1 unit  0121585
Cutting tool

For processing mild steel between 300 and 500 N/mm2

Set of 10  1263029
Set of 2  1263021
55° special-purpose stripper

For an angle of bevel between 20° and 55°

1 unit  0032119
Pedestal

Pedestal for work station

1 unit  0003677
TruTool TKF 1500 with 2-speed gearbox, 1st speed
TruTool TKF 1500 with 2-speed gearbox, 2nd speed
Maximum chamfer lengths / Maximum chamfer heights
Maximum chamfer length, steel 400 N/mm² 15 mm 15 mm
Maximum chamfer height, steel 400 N/mm² 10.6 mm 10.6 mm
Maximum chamfer length, steel 600 N/mm² 11 mm 9 mm
Maximum chamfer height, steel 600 N/mm² 7.8 mm 6.4 mm
Maximum chamfer length, steel 800 N/mm² 9 mm 6 mm
Maximum chamfer height, steel 800 N/mm² 6.4 mm 4.2 mm
Radii
Smallest radius 55 mm 55 mm
General
Working speed (max.) 1.25 m/min 2 m/min
Nominal power consumption 2600 W 2600 W
Sheet thickness 4 mm - 160 mm 4 mm - 160 mm
Dimensions
Length 607 mm 607 mm
Height 361 mm 361 mm
Weight
Weight 19.5 kg 19.5 kg

This product range and information may vary depending on the country. Subject to changes to technology, equipment, price and range of accessories. Please get in touch with your local contact person to find out whether the product is available in your country.
