Imagine that you are driving a car with 400 hp – but no matter how much you step on the gas, your car just cannot translate the engine's capacity onto the road. Our machines are designed so that the full power of the laser really hits the sheet metal to prevent you from having that problem with laser cutting. The complete package of machine, laser power and functions is decisive for quality and productivity. Perfectly coordinated: only available with TRUMPF. Fully utilise laser power of up to 12kW on the workpiece – this gives you the best results even with difficult parts.
Productive processing, smooth processes
The TruLaser 5030 fiber, TruLaser 5040 fiber and TruLaser 5060 fiber impress with their high processing speed and reproducible, high part quality – even for complex contours. You can achieve excellent feed rates thanks to the solid-state laser with up to 12 kW laser power. Clever assistant systems make the complete machining process more productive and reliable than ever. Operator involvement is low; non-productive times are minimal.
High machine dynamics, even for complex contours, thanks to powerful drives and dynamic axis motions.
BrightLine fiber facilitates excellent part quality and seamless removal of the parts.
A new nozzle design reduces nitrogen consumption by up to 70% – for twice the sheet throughput.
Utilise the full power of the laser: our machines are designed so that every single kW hits the sheet. This means that not only do you achieve high feed rates, but you are also able to process the workpiece productively.
Smart nozzle automation ensures a high quality of nozzle – even in fully automatic operation. The nozzle changer can be pulled out while the machine is cutting and be set up parallel to production.
The multi-award-winning Touchpoint HMI enables you to operate the machine much faster and more intuitively, with the same excellent performance.
Quickly and easily machine sheet metal measuring 6 x 2 m.
With the CoolLine function, you can even create fine contours in thick mild steel.
TruLaser 5030 fiber
|
TruLaser 5040 fiber
|
TruLaser 5060 fiber
| |
---|---|---|---|
Weight | |||
Weight, basic machine | 7850 kg | 9700 kg | - |
Maximum speed | |||
Simultaneous | 280 m/min | 280 m/min | 280 m/min |
Working range | |||
X axis | 3000 mm | 4000 mm | 6000 mm |
Y axis | 1500 mm | 2000 mm | 2000 mm |
Maximum workpiece weight | - | - | - |
Laser-specific data - TruDisk 4001 | |||
Maximum laser power | 4000 W | 4000 W | 4000 W |
Maximum sheet thickness, mild steel | 25 mm | 25 mm | 25 mm |
Maximum sheet thickness, stainless steel | 20 mm | 20 mm | 20 mm |
Maximum sheet thickness, aluminium | 20 mm | 20 mm | 20 mm |
Maximum sheet thickness, copper | 8 mm | 8 mm | 8 mm |
Maximum sheet thickness, brass | 8 mm | 8 mm | 8 mm |
Laser-specific data - TruDisk 6001 | |||
Maximum laser power | 6000 W | 6000 W | 6000 W |
Maximum sheet thickness, mild steel | 25 mm | 25 mm | 25 mm |
Maximum sheet thickness, stainless steel | 25 mm | 25 mm | 25 mm |
Maximum sheet thickness, aluminium | 25 mm | 25 mm | 25 mm |
Maximum sheet thickness, copper | 10 mm | 10 mm | 10 mm |
Maximum sheet thickness, brass | 10 mm | 10 mm | 10 mm |
Laser-specific data - TruDisk 8001 | |||
Maximum laser power | 8000 W | 8000 W | 8000 W |
Maximum sheet thickness, mild steel | 25 mm | 25 mm | 25 mm |
Maximum sheet thickness, stainless steel | 40 mm | 40 mm | 40 mm |
Maximum sheet thickness, aluminium | 25 mm | 25 mm | 25 mm |
Maximum sheet thickness, copper | 10 mm | 10 mm | 10 mm |
Maximum sheet thickness, brass | 10 mm | 10 mm | 10 mm |
Laser-specific data - TruDisk 10001 | |||
Maximum laser power | 10000 W | 10000 W | 10000 W |
Maximum sheet thickness, mild steel | 30 mm | 30 mm | 30 mm |
Maximum sheet thickness, stainless steel | 40 mm | 40 mm | 40 mm |
Maximum sheet thickness, aluminium | 30 mm | 30 mm | 30 mm |
Maximum sheet thickness, copper | 16 mm | 16 mm | 16 mm |
Maximum sheet thickness, brass | 12 mm | 12 mm | 12 mm |
Laser-specific data - TruDisk 12001 | |||
Maximum laser power | 12000 W | 12000 W | 12000 W |
Maximum sheet thickness, mild steel | 30 mm | 30 mm | 30 mm |
Maximum sheet thickness, stainless steel | 40 mm | 40 mm | 40 mm |
Maximum sheet thickness, aluminium | 30 mm | 30 mm | 30 mm |
Maximum sheet thickness, copper | 16 mm | 16 mm | 16 mm |
Maximum sheet thickness, brass | 12.7 mm | 12.7 mm | 12.7 mm |
Consumption values | |||
Average power input in production - TruDisk 4001 | 13 kW | 13 kW | 13 kW |
Average power input in production - TruDisk 6001 | 15 kW | 15 kW | 15 kW |
Average power input in production - TruDisk 8001 | 17 kW | 17 kW | 17 kW |
Average power input in production - TruDisk 10001 | 25 kW | 25 kW | 25 kW |
Average power input in production - TruDisk 12001 | 29 kW | 29 kW | 29 kW |
The technical data of all product versions as a download.
High productivity and the best quality: powerful functions guarantee the best processing results.
Process reliability and operator support

Mild steel becomes extremely hot during laser cutting and may melt uncontrollably. With CoolLine, this does not happen. During processing, nozzles with precise bore holes spray water mist in a circle around the laser beam onto the workpiece. The vaporisation energy of the water means that the material around the laser beam is cooled. CoolLine therefore enables new geometries, closer nesting and increases process reliability for the processing of thick mild steel considerably.

One glance is enough: thanks to the new Condition Guide function, you are always informed about the condition of your machine. A traffic light system shows the status of important elements that influence the cutting capability of the machine. Condition Guide will give you recommendations for action as required. Process diagrams facilitate forecasting as to when action may need to be taken. Maintenance work can therefore be planned efficiently.
AdjustLine enables the easy adjustment of the cutting process to materials of different quality. The function increases process reliability, above all when cutting material of a poor quality. This results in fewer waste parts and lower material costs for you. The operator can switch AdjustLine on or off at any time – programming is not required.
Collision protection for your cutting head guarantees the highest process reliability. You benefit from shorter non-productive times due to increased machine availability. In the event of collisions, damage to the cutting head is avoided.
The Dot Matrix Code function enables parts to be labelled quickly and with process reliability using a standardised industrial code. Within seconds, the laser in your laser flatbed machine applies a 2D code (data matrix) made out of dots onto a part. It contains information for the process chain. The code serves, for example, to call up the corresponding program at the next machine.
Using the MobileControl app, you can operate and monitor your machines easily and with flexibility as the app transmits the interface of the standard control panel onto the touch screen of your tablet PC. The app enables you to call up machine information at different places in the working environment of the machine, such as the clearing area, or to change the program.
With Drop&Cut, remainder sheet is utilised more easily, intuitively and efficiently. A camera ensures that the live image of the machine interior appears directly on your user interface. You can position any number of part geometries on the remainder sheet. This saves a lot of time during the post-production of individual parts. Time-consuming process steps such as aligning the sheet, sheet position measurement or zero point displacement are not needed.
The Sorting Guide is a camera-based assistance system that assists the worker in removing and sorting sheet metal parts. It marks parts with different colours according to the customer order or subsequent process. This enables the worker to quickly, easily and correctly arrange the cut parts on pallets.
Clean protective glass ensures high cut quality in the long term. A sensor constantly monitors the state of the protective glass so that you know when it must be changed. Cleaning and replacement are only carried out when required, saving costs.
Autonomy
The optimal condition of the nozzle and lens is an important requirement for optimum process reliability and part quality. Smart nozzle automation combines intelligent functions, including LensLine, to increase the service life of your lenses. This is ensured even in fully automatic operation. The function independently detects and rectifies numerous issues which could impair the cutting result. This means you can plan cleaning and replacement cycles for the nozzle much more easily.
The properties of the laser beam play an important role during part production. This includes the focal position: if this is not set optimally, it impairs the condition of the parts. Smart beam control guarantees the correct focal position of the laser beam at all times, and supports you during the inspection of the cutting system. A sensor integrated into the cutting head permanently checks the position of the focus; if there are any changes, the function readjusts it. Smart beam control also opens up new diagnostics options – the machine's cutting system can be inspected remotely using remote support.
You can largely avoid the need for microjoints, saving costly reworking. The parts can also be unloaded using an automated mechanism as they do not tip over.
A camera system determines the position of inserted sheets precisely, and enables the reworking of parts which have already been cut with absolute precision. DetectLine also automatically measures a cut focusing comb and sets the focal position.

During cutting, the system monitors the kerf through the nozzle, oversees the cutting process and independently regulates the feed rate. Even if the thickness of a sheet varies, or it has been influenced by fluctuations in quality caused by rust or paint residues, the sensor system ensures the correct feed during flame and fusion cutting. Data analysis makes quick and stable cutting possible. This can prevent disruptions to cutting and noticeably reduces the number of reject parts. The operator is also relieved. They can pull up the most important process parameters or a live-image through the nozzle any time, and will be actively informed if the need for intervention arises.
Productivity
Quick and economic – without compromising on quality: with Highspeed, you can set new records with the solid-state laser when it comes to cutting with nitrogen. As a result, you can almost double your sheet throughput for medium and thick mild steel and stainless steel sheets. It is also possible to double the feed rate. A special nozzle design also reduces your cutting gas consumption by up to 40% and even prevents burr formation on contours with sharp edges. The process also harnesses new sheet thicknesses for processing with nitrogen. In conjunction with the TruDisk 8001, the TruLaser 5030 fiber cuts mild steel with a thickness of 12 mm.
Extremely quick, extremely economical: with this Highspeed process, you can reduce your cutting gas consumption for cutting with nitrogen by up to 70%. This is enabled by a patented nozzle design. At the same time, you can almost double your sheet throughput for medium and thick mild steel and stainless steel sheets and increase the feed rate by up to 100%. Quality does not suffer as a result. Highspeed Eco even prevents burr formation on contours with sharp edges. The process also harnesses new sheet thicknesses for processing with nitrogen. In conjunction with the TruDisk 8001, the TruLaser 5030 fiber cuts mild steel with a thickness of 12 mm.

Ensuring the kilowatts hit the sheet metal: even high levels of laser power can be fully utilised with TRUMPF machines. The TruDisk laser with up to 12kW not only promises high feed rates, but more importantly processes the workpiece to the highest level of productivity. This accurate combination of laser power, machine design and intelligent functions produces the best parts in the shortest processing time. This applies to fusion cutting as well as to flame cutting, and also to more complicated applications, for example, fine contours or thick sheet metal.
Quality

BrightLine fiber turns the solid-state laser into a universal tool: the function provides you with high-quality cutting results over the entire sheet thickness range. Furthermore, all of the advantages of the solid-state laser are retained, in particular the high speeds, during thin sheet processing.

PierceLine monitors and controls the piercing process. This saves material and preserves the machine, increasing part quality and shortening the piercing time by up to 80%.

During fusion cutting in thin sheets, the innovative performance nozzles and the optimised cutting data of the performance package provide you with two advances at the same time: a jump forward in quality and considerably higher productivity.

TruTops Boost
Construct and program your laser, punching and combination punch laser machines intelligently with TruTops Boost, your all-in-one 3D solution. Numerous automated processes save you time-consuming routine processes and the joint nesting pool saves time and material. You also always have an overview of all manufacturing orders and order-based work.

TruTops Monitor
Reduce your idle time. Record and analyse machine data, such as idle states, error messages, causes of malfunctions and maintenance periods for all of your production workplaces. If an idle state or a malfunction occurs, TruTops Monitor informs you immediately of the cause, allowing you to respond quickly.

Software
The extensive range of TruTops software supports you throughout the entire production process. Control your operational workflow in a simple and targeted manner, from managing your customer orders and purchasing processes to delivery of the produced parts. Through the direct coupling with the machine control, you can keep a constant eye on the status of your orders.
Choose the right automation components for your laser cutting machine from a large modular system. From semi-automatic loading to a fully automatic processing cell with storage connection, TRUMPF provides solutions which optimise your process chain.

Loading
Your entry into automation: the LoadMaster enables the automatic loading of your machine with raw sheets.

Loading and unloading
The LiftMaster Compact loads and unloads your machine completely automatically. The LiftMaster Linear Basic increases the utilisation of up to two machines

Loading and unloading / part sorting
The LiftMaster automation solution covers a broad range of automation functions. It loads and unloads, but is also suitable for pallet handling or part removal. The LiftMaster Sort also separates finished parts from the scrap skeleton. LiftMaster Store and LiftMaster Store Linear connect your system directly to the store. The SortMaster automatically sorts finished parts.

Auxiliary pallet operation
The PalletMaster Tower enables flexible material handling around the clock. It combines the automatic changing of pallets with compact storage technology.

Storage system
With the storage systems of the TruStore Series 1000 and TruStore Series 3000 you can organise your material handling according to your requirements.
This product range and information may vary depending on the country. Subject to changes to technology, equipment, price and range of accessories. Please get in touch with your local contact person to find out whether the product is available in your country.
